Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC

Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC

Large Image :  Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC

Product Details:
Place of Origin: Shandong, China
Brand Name: Lasence
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: $1,500.00/pieces >=10 pieces
Contact Now

Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC

Description
Condition: New Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Field Maintenance And Repair Service, Online Support Spare Parts Type: Laser Module
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product Key Selling Points: High Stability, Focus Adjustable, Little Beam Spot
Showroom Location: Germany Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert
Weight (KG): 0.1 KG Wavelength: 532nm, 545nm, 555nm, 561nm
Output Power: 50mW - 1W Output Power Mode: CW
Beam Divergence: 20mrad-40mrad Beam Diameter At Focus Position: ~0.3mm
Beam Mode: Multi Power Type: APC
LD Voltage: 1.8-2.3V LD Current: < 1100mA
Laser Module Length: 18x55mm

Video Decription
Recommend By Seller
Products Description
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 0



Features：
· DPSS Laser
· Various Wavelength 520nm, 530nm, 545nm, 555nm,561nm and 577nm
· Fast Rise Time
· High Reliability


Specifications
Dimensions (Unit: mm)
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 1
Wavelength
532nm, 545nm, 555nm, 561nm, 577nm
Output Power
532nm, 545nm: 50mW, 200mW, 500mW, 1W
555nm: 50mW, 200mW, 500mW, 1W
561nm: 50mW and 200mW
577nm:50mW
Beam Divergrence
max 40mrad, typ: 20mrad
Beam Diameter at output window
~ 0.5mm
Power Type
ACC
LD operating voltage
1.8-2.3V DC
LD operating current
2000 to 100000A based on differernt output power

Spectral Width
±1nm
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 2
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 3
Why Choose Us
Qingdao Lasence Co., Ltd is a high technology enterprise which is mainly engaged in R&D, production and sales of laser products.
The factory was founded in 2009. We focus on the development and production of laser modules and lasers for more than 10 years.
Our main products are DPSS lasers range from 500nm to 600nm, including dot laser module, line laser module and ring laser module,
as well as high power lasers. Our own crystal called “self-frequency doubling crystal ” is widely used with high stability and
wide temperature range -40℃ to 60℃。 These lasers can be CW, TTL or Analogue modulation, which are widely used in applications of
biomedical, medical, lighting and alignment, positioning, measurement, precision machining, construction and so on. We have 30+
engineers and have exported for nearly 10 years mainly to Europe, North America, Mid-east and East Asia. Just tell us what you
want to achieve, and Lasence will help you get there.
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 4
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 5
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 6
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 7
System(Controllable for each step)
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 8
Payment & Delivery
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 9

1. Payment

1)Payment can be arranged when order is ready before shipment.
2) TT or online via Alibaba platform.


Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 10

2. Package

1) each module in a seperate antistatic bag before packing in carton.
2) each laser is in a safe box before packing in carton.
Green Yellow Laser Dot High Power Laser Module 545nm 555nm 561nm 50mW to 1000mW with NTC 11

3. Shipping

Shipping by sea to your nearest port
Or Shipping by air to your nearest airport.
Or Shipping by DHL/FedEx/UPS/TNT to your door.
If you have any requests in package and shipping , please contact us directly
After-sales Service
Lasence Laser modules and lasers are 1 year warranty for free, all lifelong technical support and part cost supply.
(1) The warranty period is start from the date of shipment which show on the bill of loading or air waybill.
(2) Free maintenance services during the warranty period the cost involved be borne by the company, do not charge a fee to
customers, free warranty if any damage outside the warranty period, the company will charge a fee for labor costs and materials.
(3) The warranty period: company's quality problems caused by the maintenance of the freight borne by the company, if not under
warranty or man-made damage, the freight charges by the customer.

All price one the webise is just a referecen, please contact us for an accurate offer, thank you.
