0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode

0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode

Large Image :  0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode

Product Details:
Place of Origin: Shandong, China
Brand Name: Lasence
Payment & Shipping Terms:
Price: $1,000.00/pieces 1-99 pieces
Packaging Details: ESD Plastic bag, outside with carton package
Contact Now

0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode

Description
Condition: New Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Field Maintenance And Repair Service, Online Support Spare Parts Type: Laser Module
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product Key Selling Points: High Stability, Wide Temperature Range
Showroom Location: Germany Applicable Industries: Garment Shops, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Other, Advertising Company, Industry
Weight (KG): 0.2 KG Wavelength: 561nm±2nm
Output Power: 50mW Output Power Mode: CW
Beam Divergence: ≤ 50mrad Beam Diameter At Output Window: 0.5mm
Beam Mode Transverse: Multi Power Type: ACC
LD Voltage And Current: 2V , 2500mA Operating Temperature: 25℃-30℃
RoHS Compliance Declaration: Yes Port: Qingdao,China

Products Description
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 0



Features：
· DPSS Laser
·50mW@561nm
· Fast Rise Time
· High Reliability
Specifications
561nm Yellow Laser Module for medical, biological detection, science etc.

Specifications
Model Number :Y561D050-18x55-30
Mechanical Specifications
Laser HeadDiameter (mm): 18x55mm
Housing Material: Brass with gold-plating
Wavelength (nm): 561±2nm
Output Power (mW) at 25℃ at 2.5A： ≥50mW
Power Stability at const. Temperature(2) : +/- 5%, +/- 10%
Output Power Mode:CW
Laser Class: 3B
Beam Divergence (mrad)：≤ 40mrad
Beam Diameter at Output Window (mm): 0.5mm
Beam Mode Longitude:Multi
Beam Mode Transverse:TEMno
Polarization Ratio (Linear):100:1
Power Type: ACC
LD Voltage (DC, V): 1.8-2.3v
LD Operating Current (mA) at 2V: ≤2,500
Thermistor Constants
A = 2.231e-3 B = 4.694e-5
C = 0.884e-6
Thermistor Resistance
6.6KΩ@35℃ 8.2KΩ@30℃ 10.0KΩ@25℃ 12.3KΩ@20℃ 16.4KΩ@15℃ 18.5KΩ@10℃

For datasheet, please contact with Lasence sales.

0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 1
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 2
Company Profile
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 3
Qingdao Lasence Co., Ltd is a high technology enterprise which is mainly engaged in R&D, production and sales of laser products. The factory was founded in 2009. We focus on the development and production of laser modules and lasers for more than 10 years. Our main products are DPSS lasers range from 500nm to 600nm, including dot laser modules, line laser modules and ring laser modules, as well as high power lasers. Our own crystal called “self-frequency doubling crystal ” is widely used with high stability and wide temperature range -40℃ to 60℃. These lasers can be CW, TTL or Analogue modulation, which are widely used in applications of biomedical, medical, lighting and alignment, positioning, measurement, precision machining, construction and so on. We have exported for nearly 10 years mainly to Europe, North America, Mid-east and East Asia. Just tell us what you want to achieve, and Lasence will help you get there.
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 4
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 5
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 6
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 7
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 8
Exhibition
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 9
Working Environment
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 10
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 11
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 12
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 13
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 14
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 15
Payment & Delivery
0.5mm Beam Diameter 561nm 50mW DPSS Yellow Laser Module for Medical or Science CW Output Power Mode 16

Contact Details
Qingdao Lasence Co., Ltd.

Contact Person: Mrs. Sui

Tel: 18669790946

Fax: 86-532-6673-1599
