high visibility 555nm line laser module
Features：
· DPSS Laser
· Various Wavelength : 530nm, 545nm, 555nm,
· Fast Rise Time
· High Reliability
·Wide Temperature Range
·100% eye visibility at 555nm
|
Product Details:
|
| Condition: | New | Warranty: | 1 Year |
|---|---|---|---|
| After-sales Service Provided: | Free Spare Parts, Field Maintenance And Repair Service, Online Support | Spare Parts Type: | Laser Module |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Hot Product | Key Selling Points: | High Stability, Focus Adjustable, Little Beam Spot |
| Showroom Location: | Germany | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert |
| Weight (KG): | 0.1 KG | Wavelength: | 555nm±5nm |
| Output Power Before Adding Cylinder Lens: | 1mW, 6mW And 18mW (optional) | Output Power Mode: | Pulse |
| Fan Angle: | 120° | Linewidth At 7m: | Min.2-3 Mm And 4mm For 18mW |
| Line Curvature At 10m: | ±1mm | Power Type: | ACC/ Duty Cycle-50% |
| Operating Voltage: | 2.6-3V | Operating Current: | Peak: Max.500mW, Average: 430mA |
| Module Size: | 17x35mm |
Dimensions (Unit: mm) | ||||||||
Wavelength | 532nm, 545nm, 555nm | ||||||
Output Power | Can be customized from 1mW to 18mW (dot in center of the line or without- optional) | ||||||
Line width at 10m | max. 5mm/ min.2-3mm | ||||||
Deviation of Laser Beam at 10m | max.2mm | ||||||
Power Type | Input: ACC, duty cycle 50% fixed; Output: pulsed | ||||||
Operating voltage | 2.6-3V DC | ||||||
Operating current | Peak: max.500mW Average: Max.430mA | ||||||
Spectral Width | ±1nm | ||||||
