Features：
· DPSS Laser
· 500mW@555nm
· Wide Temperature Range
· Fast Rise Time
· High Reliability
The below datasheet is for 200mW, it can be up to 500mW LASER MODULE at 555nm, and can be 1000mW at 545nm.
|
Product Details:
|
| Condition: | New | Warranty: | 1 Year |
|---|---|---|---|
| After-sales Service Provided: | Free Spare Parts, Field Maintenance And Repair Service, Online Support | Spare Parts Type: | Laser Module |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Hot Product | Key Selling Points: | High Stability, Wide Temperature Range |
| Showroom Location: | Germany, Colombia | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Advertising C |
| Weight (KG): | 0.2 KG | Wavelength: | 555nm |
| Output Power: | 500mW | Output Power Mode: | CW |
| Beam Divergence: | Max 30mrad | Beam Diameter At Output Window: | 0.5mm |
| Beam Mode Transverse: | Muti-mode | Power Type: | APC |
| LD Voltage: | 1.8-2.3V | Operating Temperature: | 25-30℃ |
| RoHS Compliance Declaration: | Yes |
Dimensions (Unit: mm) | ||||||||
