Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration

Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration
Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration

Large Image :  Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration

Product Details:
Place of Origin: Shandong, China
Brand Name: Lasence
Payment & Shipping Terms:
Price: $2,500.00/pieces 1-9 pieces
Contact Now

Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration

Description
Condition: New Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Field Maintenance And Repair Service, Online Support Spare Parts Type: Laser Module
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product Key Selling Points: High Stability, Wide Temperature Range
Showroom Location: Germany Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert
Weight (KG): 0.2 KG Wavelength: 571nm±7nm
Output Power: ≥80mW Output Power Mode: CW
Beam Divergence: ≤ 50mrad Beam Diameter At Output Window: 0.5mm
Beam Mode Transverse: Multi Power Type: ACC
LD Voltage And Current: 2V , 1.2A Operating Temperature: 25℃-30℃
RoHS Compliance Declaration: Yes

Products Description
Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration 0



Features:
· DPSS Laser
·≥800 Yellow Laser
571nm±2nm
· Fast Rise Time
· High Reliability

Specifications
571 Yellow Laser Module for medical, biological detection, science etc.

Specifications
Model Number :Y571D1000-19x18x58-40
Mechanical Specifications
Laser HeadDiameter (mm): 19x18x58mm
Housing Material: Brass with gold-plating
Wavelength (nm): 571±2nm
Output Power (mW) at 25℃ : ≥800mW
Power Stability at const. Temperature(2) : +/- 1%, +/- 3%
Output Power Mode : CW
Laser Class: 3B
Beam Divergence (mrad):≤ 40mrad
Beam Diameter at Output Window (mm): 0.5mm
Beam Mode Longitude:Multi
Beam Mode Transverse:TEM1o
Polarization Ratio (Linear):100:1
Power Type: ACC
LD Voltage (DC, V): 1.8-2.3v
LD Operating Current (mA) at 2V: ≤1.2A
Thermistor Constants
A = 2.231e-3 B = 4.694e-5
C = 0.884e-6
Thermistor Resistance
6.6KΩ@35℃ 8.2KΩ@30℃ 10.0KΩ@25℃ 12.3KΩ@20℃ 16.4KΩ@15℃ 18.5KΩ@10℃

For datasheet, please contact with Lasence sales.

Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration 1
Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration 2
Company Profile
Life Science 561nm 571nm High Power Yellow Laser Module with RoHS Compliance Declaration 3
Qingdao Lasence Co., Ltd is a high technology enterprise which is mainly engaged in R&D, production and sales of laser products. The factory was founded in 2009. We focus on the development and production of laser modules and lasers for more than 10 years. Our main products are DPSS lasers range from 500nm to 600nm, including dot laser modules, line laser modules and ring laser modules, as well as high power lasers. Our own crystal called “self-frequency doubling crystal ” is widely used with high stability and wide temperature range -40℃ to 60℃. These lasers can be CW, TTL or Analogue modulation, which are widely used in applications of biomedical, medical, lighting and alignment, positioning, measurement, precision machining, construction and so on. We have exported for nearly 10 years mainly to Europe, North America, Mid-east and East Asia. Just tell us what you want to achieve, and Lasence will help you get there.
