532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption

532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption

Large Image :  532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption

Product Details:
Place of Origin: China
Brand Name: Lasence
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: $106.00/pieces 10-99 pieces
Contact Now

532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption

Description
Condition: New Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Field Maintenance And Repair Service, Online Support Spare Parts Type: Laser Module
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product Key Selling Points: High Stability, Wide Temperature Range
Showroom Location: Germany Applicable Industries: Building Material Shops, Food & Beverage Factory, Construction Works , Industry
Weight (KG): 0.02 KG Wavelength: 532nm ±2nm
Output Power For Dot: 4-5mW Output Power Mode: CW
Beam Divergence: ≤1.7mrad Beam Mode: TEMoo
Power Type: APC Voltage: 3.0-6.0V
Driver Current At 5V: ≤200mA Module Size: 12x41mm
Operating Temperature: 15 To 50℃

Video Decription
Recommend By Seller
Products Description
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 0



Features：
· DPSS 532nm Green dot laser module
· Fast Rise Time
· High Reliability
TEMoo
Dimensions (Unit: mm)
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 1
Wavelength
532nm±2nm
Output Power
4-5mW
Operating Case Temperature
15 to 50℃
Power Stability
±5% at constant temperature
Beam Divergence
Max 1.7mrad
Dimentions
φ12x41mm
Beam
dot laser
Beam Roudness
70% to 100%
Woking Volatage
5V
Working Current
≤ 200mA
Rise Time
< 2 sec.
Lifetime
5000 hours
Rise Time
< 2sed.
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 2
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 3
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 4
Why Choose Us
Qingdao Lasence Co., Ltd is a high technology enterprise which is mainly engaged in R&D, production and sales of laser products. The factory was founded in 2009. We focus on the development and production of laser modules and lasers for more than 10 years. Our main products are DPSS lasers range from 500nm to 600nm, including dot laser module, line laser module and ring laser module, as well as high power lasers. Our own crystal called “self-frequency doubling crystal ” is widely used with high stability and wide temperature range -40℃ to 60℃。 These lasers can be CW, TTL or Analogue modulation, which are widely used in applications of biomedical, medical, lighting and alignment, positioning, measurement, precision machining, construction and so on. We have 30+ engineers and have exported for nearly 10 years mainly to Europe, North America, Mid-east and East Asia. Just tell us what you want to achieve, and Lasence will help you get there.
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 5
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 6
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 7
System(Controllable for each step)
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 8
Payment & Delivery
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 9

1. Payment:

1)Payment can be arranged when order is ready before shipment.
2) TT or online via Alibaba platform.
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 10

2. Package

1) each module in a seperate antistatic bag before packing in carton.
2) each laser is in a safe box before packing in carton.
3)inner foam protection
532nm ±2nm Green Laser Module Diodes Pumped Solid State Module Green with Consumption 11

3. Shipping

Shipping by sea to your nearest port
Or Shipping by air to your nearest airport
Or Shipping by DHL/FedEx/UPS/TNT to your door
After-sales Service
Lasence Laser modules and Lasers are1 year warranty for free, all lifelong technical support and part cost supply.
(1) The warranty period is start from the date of shipment which show on the bill of loading or air waybill.
(2) Free maintenance services during the warranty period the cost involved be borne by the company, do not charge a fee to
customers, free warranty if any damage outside the warranty period, the company will charge a fee for labor costs and materials.
(3) The warranty period: company's quality problems caused by the maintenance of the freight borne by the company, if not under
warranty or man-made damage, the freight charges by the customer.

Kindly be noted the price on the website is just for your reference, please contact us directly for an accurate offer. Mailbox: lara.sui@lasence.com or
