Features：
· DPSS 532nm 545nm Green dot laser module
· Fast Rise Time
· High Reliability
TEMoo
1 to 20mW
|
Product Details:
|
| Condition: | New | Warranty: | 1 Year |
|---|---|---|---|
| After-sales Service Provided: | Free Spare Parts, Field Maintenance And Repair Service, Online Support | Spare Parts Type: | Laser Module |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Hot Product | Key Selling Points: | High Stability, Wide Temperature Range |
| Showroom Location: | Germany | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advert |
| Weight (KG): | 0.02 KG | Wavelength: | 532nm ±2nm Or 555nm±2nm |
| Output Power For Dot: | 1mW, 5mW, 10mW, 20mW | Output Power Mode: | CW |
| Beam Divergence: | ≤1mrad | Beam Mode: | TEMoo |
| Power Type: | APC | Voltage: | 2.8-5.2V |
| Driver Current At 5V: | ≤290mA | Module Size: | 12x35mm To 12x47.5mm |
| Operating Temperature: | 15 To 50℃ |
Dimensions (Unit: mm) | ||||||||
Wavelength | 532nm/545nm±2nm | ||||||
Output Power | 1-20mW | ||||||
Operating Case Temperature | -30 to 50℃ | ||||||
Power Stability | ±5% at constant temperature | ||||||
Beam Divergence | Max 1mrad | ||||||
Dimentions | φ12x35mm for dot, 12x39.5 for line | ||||||
Beam | dot laser beam or line laser beam | ||||||
Beam Roudness | 70% to 100% for dot | ||||||
Woking Volatage | 2.8 to 5.2V | ||||||
Working Current | ≤ 290mA | ||||||
Rise Time | < 2 sec. | ||||||
Lifetime | 5000 hours | ||||||
Rohs3 | yes | ||||||
