10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW

10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW

Large Image :  10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW

Product Details:
Place of Origin: Shandong, China
Brand Name: Lasence
Payment & Shipping Terms:
Price: $500.00/pieces 1-99 pieces
Packaging Details: ESD Plastic bag, outside with carton package
Contact Now

10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW

Description
Condition: New Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Field Maintenance And Repair Service, Online Support Spare Parts Type: Laser Module
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: Hot Product Key Selling Points: High Stability, Wide Temperature Range
Showroom Location: Germany Applicable Industries: Garment Shops, Building Material Shops, Manufacturing Plant, Construction Works , Industry
Weight (KG): 0.01 KG Wavelength: 561nm
Output Power: > 10 MW , 20mW Output Power Mode: CW
Beam Divergence: Max 1.5 Mrad Beam Mode Transverse: Near TEM00
PCB Voltage: ACC 3V Max Operating Current: Max 650mA
Operating Temperature: 10 To 50℃ RoHS Compliance Declaration: Yes
Port: Qingdao,China

Products Description
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 0








Features：
·Yellow green laser
· Fast rise time
· High reliability
·Wide temperature range
Dimensions (Unit: mm)
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 1
Specifications
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 2
wavelength
560nm±2nm
Output power
10-20℃ over 10-50℃ case temperature
Power stability
±10%
Output Mode
CW
Beam Divergence
≤1.5mrad
Beam size at output window
~5mm
Beam mode
near TEMoo
Operating voltage and current
3V, ≤ 650mA, ACC PCB Type
Operating Case Temperate
10-50℃
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 3
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 4
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 5
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 6
High Eye Visibility
532nm 551nm 545nm DPSS laser modules are also optional.
Company Profile
10-20mw 561nm Yellow Dot Laser Module Max Operating Current 650mA Output Power 10 mW 7
Qingdao Lasence Co., Ltd is a high technology enterprise which is mainly engaged in R&D, production and sales of laser products. The factory was founded in 2009. We focus on the development and production of laser modules and lasers for more than 10 years. Our main products are DPSS lasers range from 500nm to 600nm, including dot laser module, line laser module and ring laser module, as well as high power lasers. Our own crystal called “self-frequency doubling crystal ” is widely used with high stability and wide temperature range -40℃ to 60℃. These lasers can be CW, TTL or Analogue modulation, which are widely used in applications of biomedical, medical, lighting and alignment, positioning, measurement, precision machining, construction and so on. We have exported for nearly 10 years mainly to Europe, North America, Mid-east and East Asia. Just tell us what you want to achieve, and Lasence will help you get there.
