Wavelength 532nm and High stability Lasence laser module laser equipment parts

Large Image : Wavelength 532nm and High stability Lasence laser module laser equipment parts

Product Details:

Place of Origin:	China
Brand Name:	Lasence

Payment & Shipping Terms:

Price:	$50.00/pieces 1-99 pieces
Packaging Details:	ESD Plastic bag, outside with carton package

Contact Now

Wavelength 532nm and High stability Lasence laser module laser equipment parts

Description

Condition:	New	Warranty:	1 Year
After-sales Service Provided:	Free Spare Parts, Field Maintenance And Repair Service, Online Support	Spare Parts Type:	Laser Module
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Marketing Type:	Hot Product	Key Selling Points:	High Stability, Wide Temperature Range
Showroom Location:	Germany	Applicable Industries:	Garment Shops, Building Material Shops, Manufacturing Plant, Retail, Industry
Weight (KG):	0.01 KG	Wavelength:	532nm
Output Power:	~10mW	Output Power Mode:	CW
Beam Divergence:	Max 1.0mrad	Beam Diameter At Output Window:	<2.5mm
Beam Mode Transverse:	TEMoo	Power Type:	APC
Voltage:	-30 To 50℃	Operating Temperature:	10 To 50℃
RoHS Compliance Declaration:	Yes	After Warranty Service:	Video Technical Support, Online Support, Field Maintenance And Repair Service
Local Service Location:	Germany	Port:	Qingdao,China

Products Description

Features：

· Fast Rise Time

· High Reliability

· Isolated Housing

· Wide Temperature Range

Dimensions (Unit: mm)

Specifications

Wavelength	532nm or 545nm
Output pwer at 25℃	CW, ~10mW
Beam spot at output window	< 2.5 mrad
Beam Roundness	70% to 100%
PCB Type	APC
Operating Volatage	2.8 to 5.2V
Operating Current	< 290mW
Operating Case Temperature	-30 to 50℃
Rohs	Yes

Company Profile

Qingdao Lasence Co., Ltd is a high technology enterprise which is mainly engaged in R&D, production and sales of laser products. The factory was founded in 2009. We focus on the development and production of laser modules and lasers for more than 10 years. Our main products are DPSS lasers range from 500nm to 600nm, including dot laser module, line laser module and ring laser module, as well as high power lasers. Our own crystal called “self-frequency doubling crystal ” is widely used with high stability and wide temperature range -40℃ to 60℃。 These lasers can be CW, TTL or Analogue modulation, which are widely used in applications of biomedical, medical, lighting and alignment, positioning, measurement, precision machining, construction and so on. We have exported for nearly 10 years mainly to Europe, North America, Mid-east and East Asia. Just tell us what you want to achieve, and Lasence will help you get there.
