CW Laser Module 561nm Green/Yellow Laser Dot with NTC 50mW-1000mW Output Power Mode

Large Image : CW Laser Module 561nm Green/Yellow Laser Dot with NTC 50mW-1000mW Output Power Mode

Product Details:

Place of Origin:	Shandong, China
Brand Name:	Lasence

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$1,500.00/pieces >=10 pieces

Contact Now

CW Laser Module 561nm Green/Yellow Laser Dot with NTC 50mW-1000mW Output Power Mode

Description

Condition:	New	Warranty:	1 Year
After-sales Service Provided:	Free Spare Parts, Field Maintenance And Repair Service, Online Support	Spare Parts Type:	Laser Module
Video Outgoing-inspection:	Provided	Machinery Test Report:	Provided
Marketing Type:	Hot Product	Key Selling Points:	High Stability, Focus Adjustable, Little Beam Spot
Showroom Location:	Germany	Applicable Industries:	Retail, Other, Industry
Weight (KG):	0.1 KG	Wavelength:	532nm, 545nm, 555nm, 561nm
Output Power:	50mW - 1W	Output Power Mode:	CW
Beam Divergence:	20mrad-40mrad	Beam Diameter At Focus Position:	~0.3mm
Beam Mode:	Multi	Power Type:	APC
LD Voltage:	1.8-2.3V	LD Current:	< 1100mA
Laser Module Length:	18x55mm

Video Decription

Recommend By Seller

Products Description

Features：

· DPSS Laser

· Various Wavelength 520nm, 530nm, 545nm, 555nm,561nm and 577nm

· Fast Rise Time

· High Reliability

Specifications

Dimensions (Unit: mm)

Wavelength	532nm, 545nm, 555nm, 561nm, 577nm
Output Power	532nm, 545nm: 50mW, 200mW, 500mW, 1W 555nm: 50mW, 200mW, 500mW, 1W 561nm: 50mW and 200mW 577nm:50mW
Beam Divergrence	max 40mrad, typ: 20mrad
Beam Diameter at output window	~ 0.5mm
Power Type	ACC
LD operating voltage	1.8-2.3V DC
LD operating current	2000 to 100000A based on differernt output power
Spectral Width	±1nm

Why Choose Us

Qingdao Lasence Co., Ltd is a high technology enterprise which is mainly engaged in R&D, production and sales of laser products.
The factory was founded in 2009. We focus on the development and production of laser modules and lasers for more than 10 years.
Our main products are DPSS lasers range from 500nm to 600nm, including dot laser module, line laser module and ring laser module,
as well as high power lasers. Our own crystal called “self-frequency doubling crystal ” is widely used with high stability and
wide temperature range -40℃ to 60℃。 These lasers can be CW, TTL or Analogue modulation, which are widely used in applications of
biomedical, medical, lighting and alignment, positioning, measurement, precision machining, construction and so on. We have 30+
engineers and have exported for nearly 10 years mainly to Europe, North America, Mid-east and East Asia. Just tell us what you
want to achieve, and Lasence will help you get there.

System(Controllable for each step)

Payment & Delivery

1. Payment

1)Payment can be arranged when order is ready before shipment.
2) TT or online via Alibaba platform.

2. Package

1) each module in a seperate antistatic bag before packing in carton.
2) each laser is in a safe box before packing in carton.

3. Shipping

Shipping by sea to your nearest port
Or Shipping by air to your nearest airport.
Or Shipping by DHL/FedEx/UPS/TNT to your door.
If you have any requests in package and shipping , please contact us directly

After-sales Service

Lasence Laser modules and lasers are 1 year warranty for free, all lifelong technical support and part cost supply.
(1) The warranty period is start from the date of shipment which show on the bill of loading or air waybill.
(2) Free maintenance services during the warranty period the cost involved be borne by the company, do not charge a fee to
customers, free warranty if any damage outside the warranty period, the company will charge a fee for labor costs and materials.
(3) The warranty period: company's quality problems caused by the maintenance of the freight borne by the company, if not under
warranty or man-made damage, the freight charges by the customer.

All price one the webise is just a referecen, please contact us for an accurate offer, thank you.

You can send your inquiry to the mailbox: lara.sui@lasence.com or

Tag:

Contact Person: Mrs. Sui

Tel: 18669790946

Fax: 86-532-6673-1599
